FD-V166

The FD-V166 is the ideal solution for modern industrial demands. By significantly shortening cycle times, it ensures peak productivity without compromising precision. Its streamlined design allows for high-density installations, effectively reducing equipment costs and factory footprint. Built with a focus on reliability, it minimizes maintenance requirements while promoting eco-friendly operations through low power consumption.
FD-V166

Main Features

Enhanced Productivity: Achieves higher output by optimizing cycle times.

Cost-Efficient Installation: Supports high-density layouts to reduce overall equipment and infrastructure costs.

Simplified Maintenance: Smart manipulator design reduces the frequency and complexity of service tasks.

Eco-Friendly Performance: Low power consumption to support your "Green Manufacturing" initiatives.

FD-V166

Technical specification

Model name
NV166
Structure
Vertical articulated type
Number of Axes 6
Wrist payload
166kg
Weight
1010kg
Load of Upper Arm
45kg（Shoulder-mounted payload: Maximum 90kg）(*1)
(*1) Shoulder-mounted maximum payload is dependent upon the mounting location.
* These specifications are subject to change without prior notice.
※ FD-V166 is the standard material handling version (not spot welding).
